Custom design for the support no catalogue carries. Sustained load, thermal movement, dynamic and seismic restraint, and pressure-thrust containment, analyzed and stamped for your specific application. Delivered under your brand.
Specification
For what the standard lines do not cover.
Pressure thrust
How much force does an unrestrained joint have to hold?
The effective diameter is on the expansion joint data sheet. It is larger than the pipe OD.
Thrust is pressure times the effective area of the joint. It does not depend on pipe wall thickness.
Design classes
Sustained load · Thermal movement · Dynamic and seismic · Pressure thrust · Travel-compensating
Deliverable
PE-sealed drawings and calculations
Analysis
Stress, FEA, thermal, seismic. Scope confirmed per project
Seal
Texas PE Firm F-13434
White-label
Available
An engineer reviews every request. No configurator, no automatic pricing.
