01
Piping Design
Layout, routing, general arrangement, isometrics, and material take-offs from concept through as-built.
CADWORX · AUTOCAD PLANT 3D · ASME B31.1 / B31.3
Services Design, engineering, and field services
Design, engineering, and field services
for systems that run under pressure.
Four decades of piping and structural work across upstream, midstream, downstream, power, and process facilities. The same practice now supporting next-generation nuclear, data center power, and large-scale desalination. We support your team from FEL-1 forward, own the detailed design and engineering, seal it, and come back to it in the field.
01 / Services
Design & Engineering
The core practice. Drawings that get built from, and the engineering behind them, both under one PE seal.
02
Piping Engineering
Line sizing, specification development, hydraulics, flexibility, and code compliance across the pressure envelope.
ASME B31.1 · B31.3 · API
03
Structural Design
Pipe racks, support structures, platforms, and foundations, drawn and detailed for fabrication.
AISC · ACI · STAAD
04
Structural Engineering
Load path analysis, member sizing, connection design, and structural assessment of existing assets.
AISC · ACI · IBC
02 / Services
Specialty Engineering
The analysis that decides whether a design survives thermal cycling, dynamic loading, and aggressive service. This is where four decades of failure analysis pays for itself.
05
Pipe Stress Analysis
Static and dynamic analysis, thermal cycling, nozzle loads, and finite element analysis on piping, supports, and equipment.
CAESAR II · AUTOPIPE · NOZZLE PRO
06
Pressure Vessels & Mechanical
Vessel and heat exchanger design, re-rating, fitness-for-service, and nozzle load evaluation.
ASME VIII · API 579 · API 510
07
Materials & Specification Development
Material selection, specification development, corrosion engineering, failure analysis, and fracture mechanics for aggressive service.
NACE · API 571 · FITNESS-FOR-SERVICE
03 / Services
Field Services
Systems already in the ground, running, and changing. We walk them down, assess what is actually installed against what it is actually doing, and tell you what needs to happen. Field construction is not our scope. Field engineering is.
08
Piping System Assessments
Walkdowns of systems in service. Condition, configuration, support adequacy, and code compliance against as-built reality rather than the original drawing.
09
Structural Member Inspections
Condition assessment of racks, platforms, and supporting steel, with remaining life evaluation and remediation design.
10
Pipe Support Evaluations
Evaluation of installed supports against actual thermal movement, dynamic loading, and pressure thrust, including restraint of expansion joints.
11
Existing System & Asset Integrity
Facility inspection programs, integrity monitoring, and remaining life assessment.
API 570 · API 653 · RBI
The lifecycle
From FEL support through field service.
We support your team through front end loading, FEL-1 to FEL-3, then take ownership of detailed design and engineering, PE-sealed deliverables, and fabrication through our partner network. Once the system is running, our field services team comes back to it.
Field construction is not our scope. Field engineering is.
- 01
FEL-1
Concept selection, feasibility, and early sizing.
WE SUPPORT
- 02
FEL-2
Preliminary design development and definition.
WE SUPPORT
- 03
FEL-3 / FEED
Front end engineering design, scope, and cost basis.
WE SUPPORT
- 04
DETAILED DESIGN & ENGINEERING
Full design and analysis. Stress, supports, materials, structural, and every drawing needed to build.
ISOMETRICS · STRESS REPORTS · SPECIFICATIONS · MTOs
WE OWN
- 05
PE STAMP & SEAL
Certification by a Texas-registered professional engineer. This is the legal instrument that lets the work be built.
PE-SEALED DRAWINGS & CALCULATIONS
WE OWN
- 06
FABRICATION
Shop oversight, inspection, and delivery through our established fabrication partner network.
FABRICATION DRAWINGS · SHOP OVERSIGHT · DELIVERED SPOOLS
PARTNER NETWORK
- 07
FIELD SERVICES
Assessment, inspection, and evaluation of systems in service.
WE OWN
How we engage 01 02 03
Three ways to work with us.
PACKAGE SCOPE
You hand us a defined package. Piping, stress, vessels, structural. We return it PE-sealed on an agreed schedule.
BENCH EXTENSION
You need senior discipline capacity for a defined period. We embed with your project team without you carrying headcount.
DESIGN & ENGINEERING THROUGH FABRICATION
We carry the scope from detailed design and engineering into fabrication through our partner shops and deliver finished, sealed hardware.
